LED pixel light

20mm single color/RGB LED pixel light

Application:
1. Advertising sign letters
2. digital panel
3. decorative lights for holiday
Product description: G2001 20mm single color/RGB LED pixel light
INQUIRY

G2001 20mm single color/RGB LED pixel light

♦♦ Specification

Item	20mm String LED Pixel
Model	G2001---20mm String LED Pixel
Storage Temperature	-40℃-60℃
Operating Temperature	-40℃-60℃
Color Rendering Index(Ra)	80
Viewing Angle	160 °
Power Dissipation	0.5W
Power	0.5W
Optical Attenuation	1%
Luminous Flux	20lm
Working Voltage	DC05V/12V
Chip Source	Taiwan Epistar
Body Material	PVC
LED Type	SMD5050
Size	20mm
Lifespan	30,000hours
Certification	CE, ROHS
Color	Full color change
OEM/ODM	Welcome
Protection	IP67
Qty / String	50pcs

♦♦ Features

1.This round single color&super colorful 20mm pixel LED is 50pcs in a string,
2.10cm 20AWG wire length between each LED,wire size:20A G,
3.It used a silicon case make waterproof by inject glue, seal structure
4.20mm diameter 35mm deep from the top of the LED to the back of the rubber,
5.DC5V for the RGB full color model and DC12V for the single color model.
6.4Pin JST SM connector (non-waterproof) soldered in each end of string,
7.The extra 2 single wire for powering in input side.
